ET-IPC-SD20
Single Disc SD 20
With a working width of 505mm, an engine power of 1600W, and a brush speed of 154rpm, the SD 20 is the most powerful single-disc machine in the IPC range.
505 mmWorking Width
154 RpmBrush Speed
240 VVoltage
Specification
- Working Width
- 505 mm
- Brush Speed
- 154 Rpm
- Voltage
- 240 V
- Frequency
- 50 Hz
- Brush Motor Rating
- 1600 W
- Brush Contact Pressure
- 34,9 g/cm²
- Under-Ride Height
- 330 mm
- Dust Pick-Up Attachment
- yes
- Noise level
- < 54 dbA
- Transmission
- planetary gear
- Power Supply Cable
- 12 m
- Weight (without accessories)
- 49 KG
- Dimensions
- 1200x625x505 mm
Also in Single Disc
Ask us about this machine
Tell us the floor area, the surface and the shift pattern and we will confirm whether this is the right size, what it needs to run, and the price delivered and installed.
Request a quotation
